| LIST OF MAJOR MACHINERY | |||
| Sr. No. | Description | Capacity | Nos |
| 1 | Slitting line |
1000mm width |
3 nos |
| 2 | Slitting line |
1200mm width |
2 nos |
| 3 | Cut to length line with punching and V notching |
1000mm x 5500mm |
2 nos |
| 4 | Cut to length line with punching and V notching |
640mm x 5500mm |
1 nos |
| 5 | Cut to length line with punching and V notching |
400mmx 2500mm |
4 nos |
| 6 | Cut to length line with punching and V notching |
250mmx2000mm |
1 nos |
| 7 | Cut to length line |
400mmx2500mm |
1 nos |
| 8 | Gap wound core Machine |
315mmx∞ |
1 nos |
| 9 | Bell Type Furnance |
1.5MT / 3MT |
2 nos |
| 10 | Totoidal Winding Machine - for CT's and PT's |
ID: 150mm OD: 1000mm Height: 200mm |
1 nos |
| 11 | Toroid Tapping - for CT's and PT's |
ID: 150mm OD: 1000mm Height: 200mm |
1 nos |
| 12 | Shunt Reactor Core Cutting Line |
Upto 1100mm OD & 300mm Height |
1 nos |
| 13 | Winding Machine for Toroidal Core |
CT's / PT's and Metering Device |
5 nos |
| LIST OF TESTING EQUIPMENT | ||
| Sr.No. | Description |
Make |
| 1 | Single Sheet Tester |
Dr. Brockhaus , Germany |
| 2 | Ring Core Tester |
Dr. Brockhaus , Germany |
| 3 | Epstein Tester |
Dr. Brockhaus , Germany |
| 4 | Franklin Tester |
Dr. Brockhaus , Germany |
| 5 | Single Sheet Tester |
Soken, Japan |
| 6 | Power Analyzer |
Yokogawa WT-230,Japan |
| 7 | Particle Measuring System |
Lasair, USA |
| 8 | Instrument Transformer Test Set |
Source - Domestic |
| 9 | Standard CT (5 to 3000/5A, 0.05 Cl) |
Source - Domestic |
| 10 | Current Source 3600A, 12 KVA |
Source - Domestic |
| 11 | HV Tester – 5 KV |
Source – Domestic |
| 12 | Resistance Meter (2 mohms – 20 kohms) |
Source – Domestic |
